Which standards do your pipe fittings and flanges comply with?

We manufacture to ASME B16.5, ASME B16.47, ASME B16.36, ASME B16.9, ASME B16.11, MSS SP-97, EN 1092-1, BS 10, DIN, JIS, ISO and API standards, with materials certified to the relevant ASTM / ASME specifications such as ASTM A182, A105, A234, A403, A350 and A420.

Do you supply mill test certificates with every order?

Yes. Every shipment is supplied with EN 10204 3.1 mill test certificates, and each piece is marked with its heat number so chemistry and mechanical properties can be traced back to the original melt. Third-party inspection by the buyer's nominated agency can be arranged on request.

Which materials do you keep in ready stock?

We hold ready stock in stainless steel (304, 304L, 316, 316L, 904L), duplex and super duplex, carbon steel (A105, A234 WPB, A350 LF2), alloy steel (F11, F22, WP11, WP22) and nickel alloys including Inconel, Hastelloy, Monel and Incoloy, as well as titanium grades.

Can you manufacture custom or non-standard piping components?

Yes. We produce custom-made piping connections to customer drawings, including sizes larger than 4 inch, special bores, non-standard pressure classes and open die forgings.

What fastener sizes and grades can you produce?

We produce high tensile bolts and nuts from M20 to M72 in metric and 3/4 inch to 3 inch in UNC, in property classes 8.8, 10.9 and 12.9, as well as ASTM A193 B6, B7, B8, B8M stud bolts and ASTM A194 2H heavy hex nuts.

Which countries do you export pipe fittings and flanges to?

Our main export markets include the UAE, Saudi Arabia, Qatar, Oman, Turkey, Egypt, Malaysia, Indonesia, the Philippines and Singapore, with sales representation in Poland, Italy, the UK, the USA and other countries.

BRT POM 1/4 NPT 3/8NPT In-Line Pipe Thread Shut Valved CPC Threaded Adapter Quick Disconnect NPT Pipe Threaded Coupling 120psi

1 / 5

BRT POM 1/4 NPT 3/8NPT In-Line Pipe Thread Shut Valved CPC Threaded Adapter Quick Disconnect NPT Pipe Threaded Coupling 120psi

Send Inquiry

Product Description

Product Specifications

Product Name	BRT POM 1/4 NPT 3/8NPT In-Line Pipe Thread Shut Off Valved CPC Threaded Adapter Quick Disconnect NPT Pipe Threaded Coupling
Body Material	POM (Acetal) / Almond PP / Grey PP / ABS / Stainless Steel / Customizable
Body Color	Natural White / Black / Almond / Grey / Customizable
Tubing Size	1/16'' ID / 1/8'' ID / 3/16'' ID / 1/4'' ID / 5/16'' ID / 3/8'' ID
O-ring Material	Buna-N / EPDM / FKM / Silicone / Customizable
Spring / Pin / Thumb Latch	Stainless Steel
Temperature Range	-40°F - 180°F
Operating Pressure	Vacuum to 120 psi (8.3 bar)
Valve Option	Valved (Shut-off) or Non-valved (Straight Through)
Mounting / Connection Option	In-line / Panel Mount / Elbow / NPT BSPT Threaded / PTF

Product Visuals & Configurations

Frequently Asked Questions (FAQ)

What is the difference between Valved and Non-valved options?

Valved (shut-off) couplings automatically stop fluid flow upon disconnection to prevent leakage. Non-valved (straight through) options maintain an unrestricted flow path without an automatic shut-off mechanism.

What operating pressures and temperatures can this coupling handle?

This coupling operates within a pressure range of vacuum up to 120 psi (8.3 bar) and is rated for temperatures ranging from -40°F to 180°F.

Which body materials are available for custom requirements?

Standard and customizable materials include POM (Acetal), Almond PP, Grey PP, ABS, and Stainless Steel, allowing you to select compatibility based on your chemical and application demands.

What sealing O-ring materials are offered?

O-rings are available in Buna-N, EPDM, FKM, and Silicone to provide resistance across various fluids, solvents, and environmental conditions.

Can these quick disconnects fit various tubing sizes?

Yes, they are compatible with tubing inner diameters (ID) including 1/16'', 1/8'', 3/16'', 1/4'', 5/16'', and 3/8'' across various termination types such as In-line, Panel Mount, and NPT/BSPT threads.
