Our comprehensive production program integrates custom duplex forging, CNC precision machining, and pressure-boundary compliance according to ASTM A182, ASME B16.5, DIN, and JIS parameters.
Combining three decades of metallurgical forging expertise with ISO 9001 certified quality architecture and EIL / IBR statutory approvals for critical project deliveries.
Government of India recognized export establishment with verified supply pipelines servicing key energy centers in the UAE, Saudi Arabia, Qatar, USA, and Europe since 1991.
Fully compliant with Engineers India Limited (EIL) and Indian Boiler Regulations (IBR). Certified for strict deployment across offshore platforms and ADNOC-audited scopes.
Strict EN 10204 3.1 Mill Test Certification supplied with every shipment. Individual piece laser/die-stamping guarantees full chemical and mechanical tracking to original ingots.
Comprehensive open-die and closed-die forging setups capable of turning special custom bores, non-standard pressure classes (up to 2500# / PN400), and large-diameter flanges.
A rigorous examination of grain boundaries, pitting resistance equivalent numbers (PREN), mechanical yield strengths, and manufacturing standards for high-chloride pipeline interconnects.
Duplex stainless steels boast an engineered biphasic microstructure containing approximately equal parts of austenite and ferrite. This balanced crystalline geometry imparts twice the yield strength of traditional 304/316 austenitic steels while suppressing stress corrosion cracking (SCC).
Pitting and crevice corrosion represent catastrophic failure mechanisms in subsea lines and desalination plants. Our duplex and super duplex flanges maintain high Pitting Resistance Equivalent Numbers (PREN = %Cr + 3.3%Mo + 16%N), ensuring long-term surface passivation.
Improper hot working or uncontrolled cooling leads to devastating precipitation of intermetallic phases like Sigma (σ) and Chi (χ), which cripple impact toughness. Our thermal cycles are held to rigorous solution annealing parameters followed by immediate water quenching.
| Grade Family | Common Designation / UNS | Tensile Strength (MPa) | Yield Strength (0.2% Offset, MPa) | Typical PREN Range | Core Industrial Application |
|---|---|---|---|---|---|
| Austenitic Stainless | AISI 316L / UNS S31603 | 485 – 515 | ≥ 170 – 205 | 23 – 25 | General chemical processing, food industry, mild utilities |
| Standard Duplex | 2205 / UNS S31803 / S32205 | 655 – 680 | ≥ 450 | 35 – 38 | Offshore topsides, sour gas gathering, cargo piping, evaporators |
| Super Duplex | 2507 / UNS S32750 | 750 – 800 | ≥ 550 | 42 – 45 | Deepwater risers, subsea manifolds, SWRO desalination, sour wells |
| Hyper Duplex | UNS S32707 / UNS S33207 | ≥ 900 | ≥ 700 | > 49 | Extreme high-pressure high-temperature (HPHT) aggressive acids |
How digital quality assurance, material lightweighting, and aggressive energy transition dynamics are shaping the next decade of flange sourcing.
As Carbon Capture, Utilization, and Storage (CCUS) projects and supercritical CO2 transport lines scale globally, piping systems encounter corrosive wet carbonic acid environments. Super Duplex flanges are rapidly superseding standard carbon steel clad pipelines due to superior resistance to carbonic breakdown and lower lifecycle maintenance costs.
Global operators are abandoning manual paper documentation. Future procurement frameworks require cryptographically verified digital material passports conforming to EN 10204 3.1/3.2, documenting Charpy V-Notch impacts, ferrite percentage calculations via Fischer Feritscope, and precise heats from electric arc furnace (EAF) melts.
With duplex nickel and molybdenum input costs remaining volatile, tier-1 manufacturers are turning to closed-die isothermal forging. This dramatically minimizes raw material waste, decreases subsequent CNC cycle hours, and creates optimal contiguous grain flow patterns across flange neck transitions.
Essential answers regarding material certifications, machining tolerances, inspection frameworks, and global export packaging.
We manufacture duplex flanges strictly in line with ASME B16.5 (for NPS 1/2 through 24), ASME B16.47 Series A & B (for NPS 26 through 60), EN 1092-1, BS 4504, DIN, and JIS standards. Dimensional variations, facing finishes (serrated concentric/spiral, smooth 125–250 Ra), and bore tolerances comply precisely with ASME specifications and customized engineering prints.
The ferrite content must be meticulously controlled between 40% and 60% to maintain dual-phase mechanical performance. We determine phase equilibrium using quantitative metallography according to ASTM E562 and verify parts non-destructively on finished forgings using digital magnetic induction Feritscopes calibrated to international standards.
Yes. Our in-house open-die and closed-die forging setups allow us to produce bespoke components, including heavy-wall weld neck flanges, long weld necks (LWN), orifice flange assemblies (ASME B16.36), swivel ring flanges, and compact flanges rated up to ASME Class 2500 and API 10,000 PSI.
Every shipment is accompanied by an EN 10204 Type 3.1 Mill Test Certificate containing real heat analysis, mechanical tensile/yield data, Charpy impact test values at sub-zero temperatures (-40°C), and ASTM G48 Method A ferric chloride pitting test reports. Third-party inspection (TPI) by DNV, Lloyd's Register, TÜV, Bureau Veritas, or SGS is regularly facilitated.
Machined gasket sealing faces (Raised Face, Flat Face, RTJ grooves) are coated with rust-inhibiting peelable compound, covered with durable plastic cap protectors, and securely packed inside ISPM-15 heat-treated, fumigated seaworthy wooden boxes with internal moisture vapor barrier bags.
Standard ASME sizes from stock forging blanks can be machined and dispatched within 7–14 days. Dedicated custom open-die forgings requiring specialized tooling, non-standard metallurgy, and localized third-party witness inspection typically run on 4 to 6-week project dispatch cycles.
Submit your line item schedule, piping datasheets, or custom CAD drawings. Our engineering team reviews NACE MR0175 / ISO 15156 parameters and delivers comprehensive commercial offers within 24 hours.
